Features
The characteristics of single-color ink cup printer.
Machine of this series adopts single –color ink-saving inkcup, using oil supply system.
Microelectronic keyboard operation controller(PIC control).
Independent pad up/down stroke and speed adjustable.
Worktable is adjustable in X.Y.Z and angle directions.
with a wide range of applications. high printing efficiency ,easy operation .they can be widely applied to print on electronic products ,home appliances ,hardware, plastics, toys and stationery, etc, satisfying various printing requirement (flat, curve, irregular surface printing).
Technical Parameters

Model	WN-126EC
Single cycle:	YES
InkCup:	Φ135 MM
Max.print(h)	300mm
Cycle/hour	1500Pcs/h
Cliche size	150mmx300mm
Printing area	ø120mm
Control panel	TOUCHscreen
Power supply	110V or 220V 50/60Hz
Electric power	20W 6Bar
External dimensions	920mmX985mmX1450mm

Application areas
This series of printing models apply to all kinds of electronic products such as computer keyboards, mobile phones, keyboards, electronic panels, telephones, game consoles and watches and clocks, toys, daily necessities, gifts and other metal plastic products LOGO, Design specific models for specific product requirements.

Ink mode:
Adopts imported ceramic ring,sealed ink cup can maximally reduce ink waste and the evaporation of the smell.ink can be stored in the cup for a long duration with stable viscosity.it’s famous for being economic and environment-friendly.
